Product information "Terminal block 3 poles"
Internal wiring: only for solid conductors and 7 stranded wire ends
Cable diameters:
External: 2 x 0.5 - 2.5 mm2
Internal:
- a) 1 x 0,5 - 1,0 mm2, releasable
- b) 1 x 0.5 - 2,5 mm2, releasable
- c) Suppression capacitor: 1 x 0.5 - 0.75 mm2, not releasable
Further markings on request
Product name: Terminal block 3 poles
Mounting method 1: Screw mount
Material: Housing: PC
Marking: N ? L
Contact opening: With integral cable release
Quantity of poles: 3
Color: white
Weight: 9
Pkg.: 500
