“外壳：高压压铸铝外壳，外部静电粉末喷涂，5mm厚耐热硅橡胶垫片，钢化安全玻璃，不锈钢螺丝，易于更换光源，方便维护，出色的耀眼光控，”
外壳颜色：浅灰色、深灰色、黑色（或指定颜色）
安装支架：垂直和水平安装均可，双向可调±15°。
LED模组：金属芯PCB上的大功率LED
“配光：采用光学PC透镜配光技术，可根据需求提供多种配光”
压板设计：外壳内部布线和结构使外观简洁，在运输过程中脱落时将透镜二次固定在PCB上
防护等级：防尘防水高达IP66，满足外界环境工作要求
| Product Name | Everstar |
| Power | 50W/100W/150W/200W/300W/360W |
| Supply voltage range | 100-305VAC |
| Temperature range | -25℃/+55℃ |
| Light guiding system | PC lenses |
| Light source | LUXEON 3030/CREE-XTE |
| Luminous intensity class | Symmetrical:G2/Asymmetrical:G1 |
| Glare index class | D6 |
| Colour temperature | 3000K,4500K,6000K |
| Colour Rendering Index | CRI>80 |
| System efficacy | Luxeon:113lm/w Gree-XTE:119.8lm/w Gree XP-G3:121lm/w |
| LED Lifetime | MIN 60,000hours |
| Power Efficiency | 92% |
| Gurrent Adjustment Range | 100W 1.33-2.66A/150W 2.1-4.17A |
| Lighting protection | Ground 10KV/Ungrounded 10KV |
| Housing material | Die-cast aluminum |
| Sealing material | Silicone rubber |
| Cover material | Tempered glass |
| Housing colour | Light Grey,Dark Grey,Black(or specified colour) |
| Wind resistance | 0.144m2 |
| Protection class | IP66 |
| Safety class | Class II |
| Shock protection | IK10 |
| Corrosion resistance | C5 |
| Mounting diameter option | 60mm |
| Suggested mounting height | 5-12m |
