| 技术参数 |
| 型号 | DR-E02 | |
| 额定电压 | 105V—480V AC | |
| 额定频率 | 50/60HZ | |
| 负载 | 16A | |
| 环境温度 | -40℃—+105℃ | |
| 尺寸 | 66mm(直径)×35.5mm(开孔) | |
| 引线长度 | #14AWG105℃ 300mm(可定制) | |
| 外壳设计 | 符合美国国家标准ANSI C136.41-2013 | |
| 安规认证 | UL&CUL(E510435 , Vol 1) | |
| 使用期限 | 8年 | |
| 停车场照明、路灯、庭院灯、走廊灯、门灯及各种LED灯饰照明控制开关 |
| Technical Parameter |
| DR-E02 | |
| Rated Voltage | 105V—480V AC | |
| Rated Frequency | 50/60HZ | |
| Load | 16A | |
| Ambient Temp | -40℃—+105℃ | |
| Size | 66mm (diameter) × 35.5mm (opening) | |
| Lead Leng | 300mm Or Customer Request(AWG#14) | |
| Shell Design | It Confrms to American National Standard ANSI C136.41-2013 | |
| Safety Certification | UL&CUL(E510435 , Vol 1) | |
| Service Life | Quality Assurance For Eight Years | |
| Applicable | Parking lot lighting, street lights, courtyard lights, corridor lights, door lights and various LED lighting control switches |
