China product chip High Power LED Encapsulation series SMD LED smd 5050
Super bright
Anti-UV capability
Luminous flux:>20lm
China product chip High Power LED Encapsulation series SMD LED smd 5050
Product Description
DP-PA5050 TOP LED Series
Features: High luminance intensity, wide view angle, high reliability for the products have passed strict reliability test.
Applications: LED backlight, LED disdlay, Automotive electronics, LED strip, LED lighiting, etc.
Type | Emitting Color | Material | View Angel | VF(V) | IV(mcd) | WL(nm) | |||
Typ | Max | Min | Typ | Min | Max | ||||
ZR-PA5050UE | Red | AlGaInP | 120° | 2.0 | 2.3 | 450 | 550 | 620 | 630 |
ZR-PA5050UG | Pure Green | InGaN | 120° | 3.2 | 3.5 | 700 | 950 | 520 | 530 |
ZR-PA5050UB | Blue | InGaN | 120° | 3.2 | 3.5 | 160 | 200 | 460 | 470 |
ZR-PA5050WW | Warm White | InGaN | 120° | 3.2 | 3.5 | 3800 | 4300 | 3000K | |
ZR-PA5050UW | White | InGaN | 120° | 3.2 | 3.5 | 4500 | 5000 | 6000K | |
ZR-PA5050RGB | Red | AlGaInP | 120° | 2.0 | 2.3 | 500 | 1000 | 620 | 625 |
Green | InGaN | 120° | 3.2 | 3.5 | 400 | 1200 | 520 | 530 | |
Blue |
