• 120V – 277V  适用电压范围 120-277V

• < 10% ATHD   ATHD < 10%

• High Power Factor 高功率因数

• End-of-Life Protection 寿终保护

• Operate 1 or 2 Lamps 带灯数量 1 or 2 灯

• TW, CR, T5HO 灯管类型 TW，CR，T5 HO

• UL, cULus  认证

• Program Preheat Start 预热启动

Product Models

Product Models 产品型号

PrintExcelCSVCopy

Lamp Operation 带灯组合

PrintExcelCSVCopyPDF

Technical Details 技术详情

Advanced Features:

• Program preheat start for extended lamp life in frequent switching applications

  预热启动可以在频繁开关环境下延长灯管寿命。

• End-of-lamp-life protection to safely remove power from the lamp as it nears end-of-life

  灯管寿终保护可以在接近灯管寿命等异常状况时自动切断切断电源。

• Cold starting to ensure proper functionality even in low temperature applications (-30°C)

  低温启动确保在低于-30°C的环境时确保正常运行。

• Improved reliability due to precision control flicker-free operation

  无频闪可靠性设计

• Auto-restart which eliminates the need to reset the power mains after lamp replacement

  自动重启功能可以在断电后自动恢复至断电前状态，更换灯管后无需手动复位

Common Specifications:

• Operating Voltage: 120V-277V (Universal Voltage)

• Frequency: 50/60 Hz

• ATHD: < 10% Protection/Output: End-of-Life Protection/Input: End-of-Life Over Current: Fuse Voltage Transients: ANSI C62.41 EMI: FCC CFR Title 47 Part 18-B consumer Regulatory Approvals: UL & cUL Listed Type 1 Outdoor High Power Factor: > .98

• Open Circuit Voltage: 600 V RMS Max.

• Ballast Maximum Case Temp.: 194o F- (90o C) – 3 year warranty

• Inherent Thermal Protection Class P

• Sound Rating A

Spec Sheets 产品说明书

Specification Sheets

• RHA-UNV-254-LT5

• RHA-UNV-454-LT5
