NEMA 5 Pin 7 Pin Photocontrol Receptacle / Socket ANSI C136.41 Standard LC-10R/5 Rotatable locking type dimming Photocontrol Receptacle The ANSI C136.41 compliant dimming receptacle and contact pads which provide an electrical and mechanical interconnection between an ANSI C136.41-2013 photocontrol and luminaire. The ANSI C136.41 compliant dimming receptacle is available with two or four dimming contacts to support either 0-30 VDC dimming methods or Digital Addressable Lighting Interface. Model code : LC-10R/5 (Addressable locking Dimming type) NEMA 5 pin 7 pin SPECIFICATIONS AND CHARACTERISTICS: ● LC-10R/5 can provide 5-wire type products: - LC-10R/5-5P------ 5 wires (2PAD): 3 main wires + 2 dimming/signal wires ● LC-10R/5 can provide 7-wire type products: - LC-10R/5-7P ------ 7 wires (4PAD): 3 main wires + 4 dimming/signal wires ● Material:【PF; BMC】 ● Specification of wires: - main wire of receptacle:14 AWG, UL1015, - signal wire:18 AWG, UL1015. ● Conform to ANSI C136.41-2013 standard ● RoHS, REACH ●Rated Load:AC Main ContactsDimming/signalRated current15A, Max250 mA, Max (ANSI C136.41)Rated voltage480 VAC/DC, Max30VAC/DC, Max
